4700mm wheelbase, Yuchai 160HP LPG vehicle

4700mm wheelbase, Yuchai 160HP LPG vehicle

An LPG truck, often called a bobtail, is a specialized vehicle designed to transport and deliver liquefied petroleum gas (propane/butane) safely. Typically featuring a fixed tank with a pump, meter, and hose, these trucks supply small bulk tanks, residential customers, and fuel stations.

Driving type :	4 x 2, Left or Right hand drive.
Truck overalldimensions :	8180 x 2550 x 2940 mm
Kerb weight:	around 5800 KGs
Payload :	around 5000 KGS
Max. gross weight :	around 10,800 KGS
LPG tank capacity :	10,000 liters
Tank design pressure:	1.77 Mpa
Working pressure:	1.61 Mpa
Working temperature:	at-20°C~+54°C
Tank material:	Q345R carbon steel
Tires:	9.00R20 16PR
Front Axle:	3.6t (drum type)
Rear Axle:	10t (drum type)
Cab type:	2080 semi-row cab
Engine:	190 hp
Transmission type:	manual
Suspension:	spring suspension.
unloading pump flow rate:	15 CBM/ hour.
LPG dispensor:	optional
Flow meter:	optional
Accessories.	Safety valve, emergency shut-off valve, level gauge, pressure gauge, thermometer,valve box etc.

Inquire Now

Product Details

Other Options: None; Air Conditioning: Without air conditioning; Rearview Mirrors: Left/right frame-type new national standard rearview mirrors (four-mirror type); ABS: Without ABS; Other Standard Configurations: Domestic trade model, sleeper, VIN stamped on the rear right of the frame, air dryer, steel air reservoir, no front under-run protection device, standard rear under-run protection; Fuel Tank: 220L iron fuel tank; Rear Axle: 10t (drum brake) / 6.5 final drive ratio; Cab Interior: Fully wrapped cab; Cab Seats: Cloth seats; Gearbox: HW90510C2; Power Steering: Enhanced power steering; Air Deflector: Without air deflector; Exhaust Brake: Equipped with exhaust brake; Front Axle: 3.6t (drum brake); Paint: Ordinary cab paint; Suspension: 9/12+9H; Tires: 9.00R20 16PR all-steel radial tires; Spring Brake: Equipped with spring brake; Clutch Booster: Equipped with clutch booster; Power Take-off: Without HW90510C2 power take-off.
