| Axle Configuration / Drive: 4×2 (Front steer, rear drive) |
| Gross Vehicle Weight: 18,000 kg |
| Curb Weight: approx. 5,500 kg |
| Emission Standard: China National VI |
| Engine: MC07H.29-60 (MAN Technology) |
| Displacement: 6.87 L |
| Rated Power: 290 HP / 213 kW |
| Max. Torque: 1,200 N·m @ 1200–1800 rpm |
| Fuel Type: Diesel |
| Transmission: HW13710 Manual 10-speed (with crawler gear) |
| Clutch: φ430mm single-plate dry clutch |
| Wheelbase: 5,200 mm (optional: 4,700 / 5,000 mm) |
| Chassis Frame: 280mm high-tensile steel straight beam, double-layer reinforced construction |
| Suspension: Multi-leaf spring front & rear (10-leaf spring assembly optional) |
| Front Axle: 4.5T steering axle |
| Rear Axle: 10-ton class 457 drive axle |
| Rear Axle Ratio: 4.875 (optional: 4.11 / 5.286) |
| Tyre: 11R22.5 18PR tubeless tyre |
| Track Width: Front 2,020 mm / Rear 1,860 mm |
| Fuel Tank: 300L aluminum alloy tank |
| Brake System: Air brake + ABS, ASR optional |
| Cab: M7 flat roof / short crew cab, 4-point suspension mounting |
| Seating Capacity: 2–3 persons |
| Overall Chassis Dimension (L × W × H): approx. 9,130 × 2,470 × 2,980 mm |
| Available Body Mount Length: 6.75–7.2 m |
| Max. Speed: 89 km/h |
| Fuel Consumption (rated load): approx. 26.8 L / 100km |
| Payload Utilization Coefficient: 1.28 |
